Vaillant electric central heating boiler eloBLOCK combinable with water storage tank
Special features of the Vaillant eloBLOCK:
- Low power consumption thanks to optimal output adjustment
- Ideal as a supplementary heater, e.g. for peak load coverage in heat pump systems
- Can be integrated into existing heating systems
- Reliable alternative to gas wall-mounted heaters when no gas connection is available
If additional heat needs to be available quickly, our technically and visually completely revised electric heating appliance eloBLOCK is a good choice. For example, you can use it for peak load coverage in a heat pump system. It is equally well suited as a simple heating solution for holiday homes or garden houses. Its use in combination with photovoltaics is particularly sustainable. Thanks to its eBUS interface, the eloBLOCK can also be integrated into existing heating systems.
Quickly and conveniently to your ideal comfort temperature
With its high-efficiency pump, optimal output adjustment, and fine output gradations, our electric heating appliance eloBLOCK is economical in power consumption. Intelligent technical details such as the safety temperature limiter and the built-in frost protection function ensure maximum operational reliability at all times.
With the finely stepped control and the precisely adjustable hot water temperature, you can quickly and conveniently reach your ideal comfort temperature at any time.
Vaillant eloBLOCK technical data:
| Heating output: |
6, 9, 12, 14, 18, 21, 24, 28 kW (depending on selection) |
| Output control: |
3-stage |
| Voltage: |
400V/50Hz |
| Height: |
740 mm |
| Width: |
410 mm |
| Depth: |
310 mm |
| Weight: |
32.6 - 35.4 kg |
Energy efficiency class Heating (A+++ - D): |
D |
Hot water comfort Heating temperature min. / max.: Hot water temperature min. / max.: |
25 - 85 °C 38 - 70 °C |
Note:
The weather-compensated controller VRC 700 or VRC 720 must be ordered separately if the eloBLOCK is used as a pure heating device.
When combining an eloBLOCK with a heat generator, a VR 32B module is required.
Installation note:
Devices with a connection value of 230V are delivered with a Schuko plug or a fixed connection (without plug) depending on the power rating. In the case of a fixed connection, a qualified specialist company must be commissioned with the installation.
For devices with a connection value of 400V, a heavy-current connection (three-phase alternating current connection) is required. Installation may only be carried out by a registered specialist company, and the approval of the respective grid operator must be obtained before initial installation.
For devices with a rated output of more than 12 kW, you require the approval of your grid operator. Please contact the grid operator or an installation company registered in the grid operator's installer directory for installation. This installation company will also assist you in obtaining the required approval from the respective grid operator.
Note on fixed electric space heaters:
In accordance with the EU Ecodesign Directive 2009/125/EC, Regulation 2015/1188 was adopted to establish requirements for the environmentally friendly design of space heaters. Installation and commissioning of electric space heaters is only permitted in combination with an external room temperature control that fulfills the following functions:
- Weekly scheduling
- Window-open detection and/or adaptive control of heating start.
You can find suitable room temperature controllers (thermostats) in our accessories section. We will be happy to advise you in detail on this topic and put together a suitable package for you.
What special feature applies to portable devices?
For portable electric space heaters, we would like to point out: "These products are only suitable for well-insulated rooms or for occasional use."
