Gastherme 💧 Vaillant ecoTEC exclusive: Top Technologie

1 2

Vaillant | SKU: 0010039093

Boil value gasher vaillant ecotec exclusive with modern technology

5.094,50 € 6.152,30 €

vAT included. Shipment will be charged at checkout.

Variant

VC VCW

Execution

20 kW 25 kW 30 kW 15 kW 25/36 kW

Product variants

Delivery and shipping

Processing time is typically 1 business day. Delivery for parcels is 1-3 business days. For freight forwarding, delivery time is 3-5 business days. Delivery times outside Germany vary.

Description

Condensing gas boiler Vaillant coTEC exclusive VC/VCW 1-7

A strong argument: Vaillant condensing gas boiler Green iQ

The ecoTEC exclusive meets the highest requirements for sustainable technologies and intelligent networking – and has been awarded the Vaillant Green iQ Label excellent.

The gas condensing boiler is produced in a resource-efficient manner and consists of around 85% high-quality recyclable materials.

GEG-safe: H2 Ready and Bio-Natural Gas

With the ecoTEC exclusive we are already taking a big step towards the future:

The device is already suitable for operation with up to 20% hydrogen* and up to 100% biomethane. Manual adjustments are not required. In addition, it is H2 Ready in accordance with the GEG, because the ecoTEC exclusive VC can be converted for operation with 100% hydrogen* using a conversion kit.

This will be available from 2026. More information about hydrogen can be found here.

The self-adapting combustion system IoniDetect also offers many advantages:

Permanently records the combustion quality via the ionization current and optimizes it in case of deviations
Detects all types of natural gas and compensates for gas quality fluctuations
Optimal combustion guaranteed

Our ecoTEC exclusive is ideal for combining with heat pumps to create sustainable hybrid systems.

By using environmental heat, a significant proportion of the required energy is generated sustainably.

Including internet module for app control

The Internet module sensoNET can be ordered free of charge for the ecoTEC exclusive using the voucher on the front of the device. In conjunction with the appropriate controller sensoDIRECT or sensoCOMFORT It allows your customers practical control via app – and you time-saving system maintenance remotely via myVAILLANT Pro.

So receive and install Your customers the Internet module:

1. Order via the QR code on the front of the device

2. Easy connection under the ecoTEC exclusive via plug-and-play

3. myVAILLANT app download and get started

Fast hydraulic balancing via app

With the integrated, communication-capable high-efficiency pump, you can perform hydraulic balancing much faster and more accurately. The app "Grundfos GO Balance" guides you step by step through the entire process and automatically calculates the recommended flow rate for each radiator. After the hydraulic balancing, you will receive a PDF documentation in the app. You can provide this to your customers as proof of professional implementation of the measure – especially helpful for funding applications.

Perfect hot water preparation in the smallest of spaces with the Vaillant condensing gas boiler VC/VCW 1-7

As a combination unit with integrated hot water preparation (VCW), the ecoTEC exclusive, with its advanced heat exchanger concept, achieves 8% higher efficiency than comparable standard units. It requires only 0.32 m² of wall space.The secondary heat exchanger with its 35 plates ensures particularly high hot water comfort.

Important technical information condensing gas boiler Vaillant VC/VCW 1-7

Modulation: 1:10
Power sizes VC: 15, 20, 25, 30 kW
Power ratings VCW: 25 kW (in hot water mode even 36 kW)

Technical data: Gas boiler Vaillant condensing VC/VCW 1-7

ecoTEC exclusive	VC 15 CS/1-7	VC 20 CS/1-7	VC 25 CS/1-7	VC 30 CS/1-7	VCW 25/36 CF /1-7
Energy efficiency class
Heating (A+++ - D)	A	A	A	A	A
Hot water (A+ - F)	-	-	-	-	A
Technical data
Heating output at 50/30 °C natural gas E, natural gas LL (Min - Max)	2.8 - 16.4 kW	2.8 - 21.6 kW	2.8 - 27.0 kW	3.8 - 32.5 kW	3.4 - 27.1 kW
Heating output at 50/30 °C LPG	5.4 - 16.4 kW	5.4 - 21.0 kW	5.4 - 26.4 kW	8.4 - 32.5 kW	-
(Min - Max)
Heating output at 80/60 °C natural gas E, natural gas LL (Min - Max)	2.5 - 14.8 kW	2.5 - 19.7 kW	2.5 - 24.7 kW	3.5 - 30.0 kW	3.0 - 25.0 kW
Heating output at 80/60 °C LPG	4.8 - 14.8 kW	4.8 - 19.7 kW	4.8 - 24.7 kW	7.8 - 30.0 kW	-
(Min - Max)
Heating output in hot water operation	20 kW	24 kW	27.5 kW	34.8 kW	36.4 kW
Natural gas E, Natural gas LL, Liquefied petroleum gas (Max)
Continuous hot water output	-	-	-	-	17.6 l/min
Efficiency at 30% according to EN 15502 Natural gas E, Natural gas LL, LPG	109%	110%	109%	110%	110%
Heat load for natural gas E, natural gas LL (Min - Max)	2.7 - 15.3 kW	2.7 - 20.4 kW	2.7 - 25.5 kW	3.7 - 30.6 kW	3.2 - 25.5 kW
Seasonal space heating efficiency ηs	93%	94%	94%	94%	94%
Addition of hydrogen	20%	20%	20%	20%	-
Bio-natural gas	up to 100%	up to 100%	up to 100%	up to 100%	up to 100%
ElectricPower consumption at 30%	28 W	47 W	54 W	58 W	49 W
Electrical power consumption (max)	81 W	59 W	91 W	80 W	61 W
Electrical power consumption in standby	2 W	2 W	2 W	2 W	2 W
Components included in electrical performance	pump	pump	pump	pump	pump
Contents heating side	2.1 l	2.1 l	2.1 l	2.6 l	2.6 l
Max operating pressure on the heating side	3 bar	3 bar	3 bar	3 bar	3 bar
Heating temperature, flow (Max)	85 °C	85 °C	85 °C	85 °C	85 °C
Connection value for natural gas E	2.2 m³/h	2.6 m³/h	3.0 m³/h	3.8 m³/h	3.6 m³/h
Connection value for natural gas LL	2.5 m³/h	3.0 m³/h	3.5 m³/h	4.4 m³/h	4.2 m³/h
Connection value for liquid gas	0.8 kg/h	1.0 kg/h	1.1 kg/h	1.3 kg/h	-
Condensation amount at 50/30 °C	1.53 l/h	2.04 l/h	2.55 l/h	3.06 l/h	2.55 l/h
Pump flow rate at ΔT 20K (residual head)	645 (200) l/h (mbar)	860 (200) l/h (mbar)	1,075 (200) l/h (mbar)	1,290 (200) l/h (mbar)	1.075 (250) l/h (mbar)
Expansion tank contents	10 liters	10 liters	10 liters	10 liters	10 liters
Tension	230 V/50 Hz	230 V/50 Hz	230 V/50 Hz	230 V/50 Hz	230 V/50 Hz
Product dimensions (height/width/depth)	720/440/348 mm	720/440/348 mm	720/440/348 mm	720/440/348 mm	720/440/382 mm
Product weight	34 kg	34 kg	34 kg	39 kg	43 kg
Heating connection (flow and return)	G 3/4	G 3/4	G 3/4	G 3/4	G 3/4
Cold water connection, hot water	G 1/2	G 1/2	G 1/2	G 1/2	G 3/4
Gas connection	20 mm	20 mm	20 mm	20 mm	20 mm
Connection air, exhaust	60/100 mm	60/100 mm	60/100 mm	80/125 mm	80/125 mm
CE	0063CU3910	0063CU3910	0063CU3910	0063CU3910	0063CU3910
category	II2N3P	II2N3P	II2N3P	II2N3P	I2N
